Futhark-J Bridge

High-performance parallel array computing for J via Futhark

Write Futhark code inline in your J programs and get automatic parallel execution on all CPU cores.

Download: futhark.ijs (v1.7.0)

What is this?

The Futhark-J Bridge lets you write Futhark code directly in your J source files. Futhark is a purely functional data-parallel programming language that compiles to highly efficient parallel code. This bridge handles compilation, caching, and FFI calls automatically.

NB. Define a Futhark function inline
double =: 'entry f (xs: []f64) : []f64 = map (*2) xs' fut

NB. Use it like any J verb
double 1 2 3 4 5
   2 4 6 8 10

Why use Futhark from J?

J is already excellent at array programming, but some workloads benefit from parallel execution across multiple CPU cores. Futhark excels at:

Compute-intensive operations - When you have many FLOPs per element
Large arrays - Parallel overhead is amortized over millions of elements
Nested parallelism - Operations that J executes sequentially

Performance Results

The library includes benchmarks comparing native J to Futhark. Here are some highlights:

Workload	Max Speedup	Notes
Mandelbrot escape	1525x	Variable iteration count per element
Logistic map (1000 iters)	14x	High compute per element
Standard deviation	2x	Multiple passes over data
Dot product	0.3x	Memory-bound; J wins

Key insight: Futhark shines when computation dominates memory access. For simple operations like dot product, native J is faster due to FFI overhead.

Quick Start

NB. Load the library
load 'futhark.ijs'

NB. Array transformations
square =: 'entry f (xs: []f64) : []f64 = map (\x -> x * x) xs' fut
square 1 2 3 4 5
   1 4 9 16 25

NB. Reductions to scalar
total =: 'entry f (xs: []f64) : f64 = reduce (+) 0 xs' fut
total 1 2 3 4 5
   15

NB. Two-input (dyadic) functions
dot =: 'entry f (xs: []f64) (ys: []f64) : f64 = reduce (+) 0 (map2 (*) xs ys)' fut
(1 2 3) dot (4 5 6)
   32

NB. Scalar input functions (v1.6.0) - use 0 : 0 for multiline Futhark
factors_src =: 0 : 0
  entry f (n: i64) : []i64 =
    let (_, _, result) =
      loop (x, i, acc) = (n, 2i64, ([] : []i64))
      while x > 1 do
        if x % i == 0
        then (x / i, i, acc ++ [i])
        else (x, i + 1, acc)
    in result
)
factors =: factors_src fut

factors 12
   2 2 3
factors 100
   2 2 5 5

NB. Fixed-size array dimensions (v1.7.0)
NB. Output has fixed inner dimension [3]
triple =: 'entry f (ns: []i64) : [][3]i64 = map (\n -> [n, n*2, n*3]) ns' fut
triple 1 2 3 4 5
   1  2  3
   2  4  6
   3  6  9
   4  8 12
   5 10 15

Features

Inline Futhark code - Write Futhark as string literals or multiline 0 : 0 blocks
Automatic compilation - First use compiles; subsequent uses are cached
Persistent context - Futhark context created once, reused for all calls
Content-based caching - SHA-256 hash ensures identical code shares libraries
Scalar and array inputs - Functions can take scalar or array inputs (v1.6.0)
Fixed-size dimensions - Support for [][32]i64 style types (v1.7.0)
Multi-dimensional arrays - 1D, 2D, 3D arrays all work seamlessly
Dynamic output sizes - Output can differ in shape from input
Helper functions - Use def to define reusable helper functions (v1.7.0)
Dyadic verbs - Two-input functions work naturally as x verb y
Clear error messages - Full Futhark compiler output on failures (v1.6.0)

Futhark Syntax Primer

Futhark entry points follow this pattern:

entry <name> (<param>: <type>) : <return_type> = <body>

Common operations:

Futhark	J Equivalent	Description
`map (*2) xs`	`2 * xs`	Element-wise transform
`reduce (+) 0 xs`	`+/ xs`	Fold to scalar
`scan (+) 0 xs`	`+/\ xs`	Running sum
`map2 (*) xs ys`	`xs * ys`	Element-wise binary op
`transpose xs`	`\\|: xs`	Matrix transpose
`flatten xs`	`, xs`	Ravel to 1D

Requirements

J 9.x with FFI support
Futhark compiler (install guide)
GCC for compiling generated C code
POSIX system: Linux, FreeBSD, or macOS

How It Works

Hash - Source code is hashed with SHA-256
Cache check - Return cached .so if exists
Compile - futhark multicore --library generates C code
Build - GCC compiles to shared library
Initialize - Futhark context created with thread pool
Execute - J calls library via FFI, passes arrays, retrieves results

The context is created at definition time and persists, so there’s no “warmup” penalty on first execution.

Files

File	Description
futhark.ijs	Main library - load this
futhark_test.ijs	Test suite (123 tests)
futhark_demo.ijs	Interactive demonstration
compute_bench.ijs	Compute-intensive benchmarks
stddev_bench.ijs	Standard deviation benchmark
dot_product_bench.ijs	Dot product benchmark
README.md	User documentation
DOCUMENTATION.md	Technical deep-dive

Sample Outputs

Test suite output - 123/123 tests passing
Demo output - Side-by-side J vs Futhark comparison
Compute benchmark - Logistic map, complex math, Mandelbrot
StdDev benchmark - Standard deviation performance
Dot product benchmark - Memory-bound operation

Example: Statistical Functions

NB. Variance
f_variance =: 'entry f (xs: []f64) : f64 = let mean = reduce (+) 0 xs / f64.i64 (length xs) in let sq_diffs = map (\x -> (x - mean) ** 2) xs in reduce (+) 0 sq_diffs / f64.i64 (length xs)' fut

NB. Standard deviation
f_stddev =: 'entry f (xs: []f64) : f64 = let mean = reduce (+) 0 xs / f64.i64 (length xs) in let sq_diffs = map (\x -> (x - mean) ** 2) xs in f64.sqrt (reduce (+) 0 sq_diffs / f64.i64 (length xs))' fut

NB. Softmax
f_softmax =: 'entry f (xs: []f64) : []f64 = let max_val = reduce f64.max f64.lowest xs in let exps = map (\x -> f64.exp (x - max_val)) xs in let sum_exps = reduce (+) 0 exps in map (\e -> e / sum_exps) exps' fut

NB. Z-score normalization
f_zscore =: 'entry f (xs: []f64) : []f64 = let n = length xs in let mean = reduce (+) 0 xs / f64.i64 n in let sq_diffs = map (\x -> (x - mean) ** 2) xs in let std = f64.sqrt (reduce (+) 0 sq_diffs / f64.i64 n) in if std == 0.0 then replicate n 0.0 else map (\x -> (x - mean) / std) xs' fut

Example: Chaining J and Futhark

Data flows seamlessly between J and Futhark:

input =: 100 200 300 400 500
   100 200 300 400 500

step1 =: f_normalize input      NB. Futhark
   0 0.25 0.5 0.75 1

step2 =: 100 * step1            NB. J
   0 25 50 75 100

step3 =: f_square step2         NB. Futhark
   0 625 2500 5625 10000

step4 =: <. step3               NB. J floor
   0 625 2500 5625 10000

step5 =: f_cumsum step4         NB. Futhark
   0 625 3125 8750 18750

Version History

Version	Changes
1.7.0	Fixed-size array dimensions (`[][32]i64`), correct parsing with `def` helper functions, 123 tests
1.6.0	Scalar input support, improved error reporting, 96 tests
1.5.0	SHA-256 hashing (128!:6) for cache keys
1.4.0	Persistent Futhark context (no warmup needed)
1.3.0	Dyadic verb support (two inputs)
1.2.0	Dynamic n-dimensional array support
1.1.0	2D array support
1.0.0	Initial release

License

MIT License
